ZKV808C5
ZKV808C5
ZKV808C5

1、System:Android 11.0/Android 13.0

2、CPU:2.3GHz octa-core

3、RAM+ROM:3GB + 32GB/4GB + 64GB/6GB + 128GB

4、Adopting Impinj E710 chip

5、Detachable 6700mAh handle battery + built-in 100mAh backup battery;

6、host IP65, meet IEC sealing standards, 6 sides can withstand multiple drops from 1.5 meters to the concrete floor impact

7、Label Horizontal locating (optional)

Share:
Product Detail
  • System Parameter
    Operating system
    Android 11.0/Android 13.0
    Processor2.3GHz octa-core
    Internal memory3GB + 32GB/4GB + 64GB/6GB + 128GB
    Expand memoryMicroSD (TF) cards can be extended up to 256GB
    SDKAndroid Java、uniapp
  • Data Communication
    WiFiIEEE802.11 a/b/g/n/ac协议 (2.4G/5G双频)
    WWAN2G: GSM850/GSM900/DCS1800/PCS1900
    3G: WCDMA:B1/B2/B4/B5/B8
    CDMA2000 EVDO: BC0
    TD-SCDMA:A/F
    4G: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A
    B28B/B34/B38/B39/B40/B41
    GPSGPS + AGPS , Beidou
    BluetoothBluetooth 5.0
    GNSSIntegrated GPS, GLONASS and Beidou; Built-in antenna, support AGPS
  • Physical Parameters
    Display screen6 inches, 2160 x 1080 resolution
    Touch screenMulti-touch; Supports wet hands and gloves
    Size177.0mm(L)×80.2 mm(W)×14.8mm(H)
    Weight626g(battery included)
    InterfaceUSB 2.0 Type-C, OTG, supports Type-C headphones
    Key1 power key, 2 scan keys, 1 multifunction key, 2 volume (+/-) keys
    TipsLED indicator, vibration
    Drop specificationWithin the operating temperature range, all 6 surfaces can withstand multiple drops from a height of 1.5 meters to the concrete floor
    IP RankHost IP65, meet the IEC sealing standard
    Storage Temp-40℃~+70℃
    Operating Temp-20℃~+50℃
    Humidity5%RH ~ 95%RH (non-condensing)
  • UHF RFID
    RFIDBased on the Impinj E710 chip
    AgreementISO/IEC18000-6C/EPC C1G2
    Recognition distance>0~25m(depending on the label or the environment)
    Group read speedUp to 1100 tags/s (with labels as environment)
    AntennaCircular polarization 4dBi
    RF output power1W(0~30dBm adjustable)
    Operating frequencyCHN:920~925MHz
    FCC:902~928MHz
    ETSI:865~868MHz
    Other multinational frequency standards (customizable)
  • NFC
    Frequency13.56MHz
    ProtocolISO14443A/B, ISO15693, NFC-IP1, NFC-IP2 etc
    Label standardM1 card (S50, S70), CPU card, NFC tag etc
    Read distance
    2-4 cm
  • Image Acquisition and Processing
    Camera13 megapixel color camera with autofocus and flash
    Scanning engineZebra:SE4710;CM60;CB300
    1DUPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS etc
    2DPDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX) etc
  • Battery
    Battery capacityBattery capacityRemovable handle
    battery 6700mAh, support battery hot swap
    Built-in 100mAh backup battery
