| Version upgrade | Demo software/remote upgrade |
| API support | .Net/.Net core/Java/C++/Android Java/communication protocol |
| Characteristic function | Automatic card reading/Support RF, EM temperature label collection |
| Size | 170mm×120mm×25mm |
| Weight | 0.5Kg |
| Shell | Die cast aluminum |
| Indicator light | Power supply, working status |
| Class of protection | IP53 |
| RFID | Based on Impinj E710 chip Based on Impinj R2000 chip (optional) |
| Agreement | ISO/IEC 18000-6B，6C/EPC C1Gen2、C2Gen2，GB/T 29768-2013(optional), GJB 7377.1(optional) |
| Recognition distance | 0m～30m(depending on the label or the environment) |
| Operating frequency | CHN：920MHz～925MHz，840MHz～845MHz FCC：902MHz～928MHz ETSI：865MHz～868MHz Other multinational frequency standards (customizable) |
| RF output power | 0dBm-33dBm（±1dBm）adjustable |
| Recognition speed | >350 times/second (recognition count ≠ recognition quantity, multiple tags can be read at once) |
| Channel bandwidth | ＜200KHz |
| Frequency stability | ≤±10ppm |
| Performance | Support multi label/dense read-write |
| Working mode | Fixed frequency/frequency hopping optional |
| Interface | RJ45，RS232 |
| I /O Interface | 2 optocoupler input (DC 0 ~ 24V), 2 relay output (DC_MAX: 30V, 2A; AC_MAX: 125V, 0.3A) |
| Equipment power | DC 24V/2.5A, operating power consumption 8W (output power 30dBm) |
| RF interface | 4 SMA ports |
| Storage Temp | -40℃～+85℃ |
| Operating Temp | -20℃～+70℃ |
| Humidity | 5%RH～95%RH（non-condensing） |
