| Size | 225mm×225mm×55.5mm(Excluding attachments) |
| Weight | 1kg |
| Class of protection | IP65 |
| Version upgrade | Demo software/remote upgrade |
| Characteristic function | Automatic card reading/Support RF, EM temperature label collection |
| API support | .Net/.Net core/Java/C++/Android Java/communication protocol |
| Agreement | ISO18000-6C/EPC C1G2 |
| Operating frequency | CHN：920MHz～925MHz FCC：902MHz～928MHz(Optional) ETSI：865MHz～868MHz(Optional) |
| RF output power | 0dBm～33dBm（±1dBm）adjustable |
| Recognition distance | 0m～20m(depending on the label or the environment) |
| Recognition speed | >300 times/second (recognition count ≠ recognition quantity, multiple tags can be read at once) |
| Antenna | Built in 8dBi circularly polarized RF antenna（FCC or ETSI） |
| Channel bandwidth | <200KHz |
| Frequency stability | ≤±10ppm |
| performance | Support multi label/dense read-write |
| Working mode | Fixed frequency/frequency hopping optional |
| RS232 | 115200bps(Default) |
| RS485 | 115200bps(Default) |
| RJ45 | 10M/100 adaptive |
| Wiegand | Wiegand 26、34、66 |
| I/0 | 1 optocoupler input, 2 IO outputs (multiplexed with Wiegand) |
| Power Supply | DC 9V~30V wide voltage |
| Power waste | 12W (output power 33dBm) |
| Storage Temp | -40℃～+85℃ |
| Operating Temp | -25℃～+70℃ |
| Relative humidity | 5%RH～95%RH(non-condensing) |
| Atmospheric pressure | 86kPa～108kPa |
| Power Supply | DC 9V~30V wide voltage |
| Power waste | 12W (output power 33dBm) |
| Compliant with certification | Compliant with Chinese radio model standards Meet FCC and CE testing standards |
| Other | Certificate of conformity, warranty card, power supply (optional), etc |
