| Industrial computer | Android/Windows PC (Optional) |
| Sensor | Infrared beam two sets (infrared trigger read, can be used to identify in and out) |
| Alarm lamp | Red and green (can be controlled separately) |
| Buzzer | 1 buzzer (interface control) |
| Firmware update | Demo |
| API support | .Net//Java/Android Java/Python/Communication protocol |
| Characteristic function | Infrared beam two sets (infrared trigger read, can be used to identify in and out)，Support RF/EM temperature sensor chips Custom output PLC |
| RFID | Based on Impinj E710 chip Based on Impinj R2000 chip |
| Agreement | ISO/IEC 18000-6B，6C/EPC C1Gen2、C2Gen2，GB/T 29768-2013(optional)，GJB 7377.1(optional) |
| Operating frequency | CHN：920MHz～925MHz，840MHz～845MHz FCC：902MHz～928MHz ETSI：865MHz～868MHz Other multinational frequency standards (customizable) |
| RF output power | 0dBm～33dBm (±1dBm) adjustable |
| Recognition distance | >400 times/second (recognition count ≠ recognition quantity, multiple tags can be read at once) |
| Recognition distance | Recognition distance 0-4m (adjusted according to application requirements) |
| Antenna | Four narrow-beam antennas (reduces misread probability) |
| Performance | Support multi label/dense read-write |
| Working mode | Fixed frequency/frequency hopping optional |
| Size | 1373mm×370mm×50mm |
| Weight | The main door weighs 9.55KG; The secondary door weighs 8.9KG |
| Class of protection | IP45 |
| Communication | RJ45 |
| Equipment power supply | 100V～240V，50Hz～60Hz(overall power consumption: ≥ 25W) |
| Storage Temp | -40℃～+85℃ |
| Operating Temp | -20℃～+70℃ |
| Humidity | 5%RH～95%RH(non-condensing) |
| Accessory | 1 Ethernet cable 1 power cord 1 infrared connection cable 2 antenna connection wires 4 expansion screws |
