| Version upgrade | Demo software |
| API support | .Net/.Net core/Java/C++/Android Java/ communication protocol |
| Characteristic function | Automatic card reading/supports RF and EM temperature tag acquisition |
| Size | 400mm×300mm×30mm |
| Weight | Approximately 2.35kg (net weight) |
| Shell | Die cast aluminum+PVC |
| Class of protection | IP53 |
| Status indication | Power indicator light |
| Power waste | DC 24V/2.5A, operating power consumption 8W (output power 30dBm) |
| RFID | Based on Impinj E710 chip |
| Agreement | ISO/IEC 18000-6C/EPC C1Gen2、C2Gen2 |
| Operating frequency | CHN：920MHz～925MHz，840MHz～845MHz FCC：902MHz～928MHz ETSI：865MHz～868MHz Other multinational frequency standards (customizable) |
| RF output power | 0dBm～33dBm（±1dBm）adjustable |
| Recognition distance | 0m～6m(depending on the label or the environment) |
| Write distance | 0m～2m(depending on the label or the environment) |
| Recognition speed | >300times/second (recognition count ≠ recognition quantity, multiple tags can be read at once) |
| Antenna | Built in 6dBi circularly polarized/near-field antenna |
| Channel bandwidth | ＜200KHz |
| Performance | Support multi label/dense read-write |
| Working mode | Fixed frequency/frequency hopping optional |
| Interface | RJ45，RS232，RS485，Wiegand |
| Customizable | External WiFi, built-in POE IEEE802.3bt power supply |
| I/O interface | 2 optocoupler input (DC 0 ~ 24V), 2 relay output (DC_MAX: 30V, 2A; AC_MAX: 125V, 0.3A) |
| Equipment power | DC 24V/2.5A（DC 9V～30V，60W） |
| Storage Temp | -40℃～+85℃ |
| Operating Temp | -25℃～+70℃ |
| Humidity | 5%RH～95%RH(non-condensing) |
